Electronic brushless motor

Micromotor 40.000 – 50.000 – 60.000 rpm delivering superb torque performance at all speeds. Features include sealed high quality bearings. So as to function impeccably on all materials and even in dusty environments.

• Ergonomic design adapted particularly for small hands.
• Due to the efficiency of the motor a study has shown that there is an approximate 20% saving in bur use.
• Excellent price-quality ratio.
• This unit runs very quietly even after extensive use – 3,000 hours.
• The motor is rated for 5,000+ hours.
• Increased capacity with reduced consumption at high performance: does not disperse energy/does not pollute.
• Maximum Ncm power: 7.8 Ncm.
• Hand piece measures: length 160 mm / ø 27 mm
• Weight 210 g. (excluding the lead)
• The handpiece is made from a plastic that will not cause allergies
• Handpiece grip ø 19 mm

This unit is suitable for various uses:

• dental laboratory
• industry
• art decoration
• jewelry
• nail art
• electronics board.

Equipment

• Support for Handpiece
• Set of tools for chuck maintenance

Technical features

• Handpiece weight: 210 g (power cable excluded)
• Feed power: 230V – 50/60 Hz (110 V on request)
• Handpiece measures: length 160 mm / ø 27 mm

Versions

• K 40P: with pedal control. 2 different speed ranges
  – Speed 1.000-30.000/40.000 rpm
  – Torque 7,8 N.cm
  – Total weight 3,500 g
• K 40T: with fully digital bench control with reverse facility and on-off foot switch
  – Speed 1,000-40,000 rpm
  – Torque 7,8 N.cm
  – Total weight 4,000 g
• K 40TV: with fully digital bench control with reverse facility and variable foot switch
  – Speed 1,000-40,000 rpm
  – Torque 7,8 N.cm
  – Total weight 4,300 g
• K 50TV: with fully digital bench control with reverse facility and variable foot switch.
  – Speed 1,000-50,000 rpm
  – Torque 7,0 N.cm
  – Total weight 4,300 g
• K 60TV: with fully digital bench control with reverse facility and variable foot switch.
  – Speed 1,000-50,000 rpm
  – Boost 60.000 rpm in 30 sec.
  – Torque 6,5 N.cm
  – Total weight 4,300 g

  Cautions

  Please keep the bur diameter and the RPM according to this diagram to prevent accidents.
  N.B. Insert the bur till the bottom.

  Bur ø	RPM
  < 2 mm	50.000/60.000
  2-4 mm	40.000
  4-8 mm	30.000
  8-18 mm	20.000
  18-28 mm	15.000
  28-40 mm	10.000
  > 40 mm	5.000
