SURGYBONE TIPS
Area of use
- Sinus Lift with crestal approach
- Extraction
- Apicectomy
- Cystectomy
- Bone Harvesting
- Ridge Expansion
- Sinus Lift
- Osteoplasy, Osteonomy
- Implant site preparation
- Tooth preparation and root planning
- Orthodontic Surgery
This brochure contains the average standard parameters provided by Silfradent which can be adjusted according to the several variables to be considered in surgery. We invite you to join us in our training courses. Our tutors will help you to understand why the Surgybone is currently the highest performance ultrasound machine.
SB P0100
Scalpel angled at 90°.
Ideally suited for sinus lift and bone harvesting.
- Cutting Tips
Bone Recovery
PWR ULT 30
VIBRA 100
SB P0200
Non-traumatic diamond tip. Ideally suited when opening the window.
- Cutting Tips
Sinus lift window
PWR ULT 30
VIBRA 100
SB P0301
Round shaped cutting scalpel, angled at 120°. Ideally suited for periodontics and bone harvesting.
- Cutting Tips
Bone Recovery
PWR ULT 30
VIBRA 100
Periodontic
PWR ULT 35
VIBRA 100
SB P0310
To lift the sinus membrane, angled at 90°, flat circular.
- Non-Cutting Tips
Sinus Lift Membrane
PWR ULT 18
VIBRA 100
SB P0321
To lift the sinus membrane, angled at 120°, flat circular.
- Non-Cutting Tips
Sinus Lift Membrane
PWR ULT 20
VIBRA 100
SB P0400
To separate the bone from the maxillary sinus.
- Non-Cutting Tips
Sinus Lift Membrane
PWR ULT 20
VIBRA 100
SB P0500
Cutting tip with scalpel top and ridged sides. Ideally suited when harvesting bone.
- Cutting Tips
Ridge Splitting
PWR ULT 40
VIBRA 100
Impacted tooth
PWR ULT 40
VIBRA 100
SB P0600
Concaved cutting tip. Ideally suited when harvesting bone from the mandible.
- Cutting Tips
Ridge Splitting
PWR ULT 45
VIBRA 100
Impacted tooth
PWR ULT 45
VIBRA 100
SB P0610
120° sharp lance tip for extraction and removal of teeth.
- Cutting Tips
Ridge Splitting
PWR ULT 45
VIBRA 100
Ankylosed root
PWR ULT 45
VIBRA 100
Impacted tooth
PWR ULT 45
VIBRA 100
SB P0700
Fast and effective cutting tip.
- Cutting Tips
Ridge Splitting
PWR ULT 46
VIBRA 100
SB P0710
Fast and effective cutting tip. Angled towards the right.
- Cutting Tips
Sagittal Osteotomy
PWR ULT 40
VIBRA 100
SB P0720
Fast and effective cutting tip. Angled towards the left.
- Cutting Tips
Sagittal Osteotomy
PWR ULT 40
VIBRA 100
SB P0750
Fast and effective cutting tip.
- Cutting Tips
Ridge Splitting
PWR ULT 45
VIBRA 100
SB P0800
Non-traumatic ballend diamond tip. Ideally suited when working close to nerve endings and blood vessels.
- Smoothing tips
Sinus Lift Membrane
PWR ULT 28
VIBRA 100
Periodontic
PWR ULT 28
VIBRA 100
SB P0805
Non-traumatic diamond tip.
Ideally suited on thin bone and cartilage.
- Smoothing tips
Sinus Lift Membrane
PWR ULT 38
VIBRA 100
SB P0830
Non-traumatic microsharpening tip. Ideally suited to prepare and compact the implant site and in case of extraction implant.
- Cutting Tips
Periodontic
PWR ULT 25
VIBRA 100
Implant and crestal sinus lift
PWR ULT 25
VIBRA 100
SB P0900
Non-traumatic polished cone shaped tip. Ideally suited for periodontal surgery.
- Cutting Tips
Periodontic
PWR ULT 28
VIBRA 100
SB P0940
Non-traumatic microsharpening tip. Ideally suited to prepare and compact the implant site and in case of post extraction implant.
- Cutting Tips
Periodontic
PWR ULT 20
VIBRA 100
Implant and crestal sinus lift
PWR ULT 20
VIBRA 100
Ankylosed root
PWR ULT 20
VIBRA 100
Kit Maxillo
Tips for Maxillofacial surgery
- Cutting Tips
SB P4010
Lance tip sharpened
on three sides
PWR ULT 40
VIBRA 100
SB P4020
Lance tip sharpened on three sides
angled towards the right
PWR ULT 40
VIBRA 100
SB P4030
Lance tip sharpened on three sides
angled towards the left
PWR ULT 40
VIBRA 100
Kit Spyne Surgery
Tips for spinal surgery.
They can work in classic mode or with pendulum wrist movement.
- Cutting Tips
SB P6010
PWR ULT 50
VIBRA 100
SB P6020
PWR ULT 50
VIBRA 100
SB P6030
PWR ULT 50
VIBRA 100
SB P6040
PWR ULT 50
VIBRA 100
Kit P.E.C.
Piezo Expansion Crest
P.E.C. non-traumatic inserts for crest expansion and for the preparation of the implantation tunnel
Original, innovative Technique created by Doctor Lancieri.
- Born out of a long experience developed by assiduously employing piezoelectric technology in biosurgery;
- Designed and manufactured to meet common surgery requirements, namely high control with low biologic impact;
- It reduces operation trauma to a minimum and make it possible to expand the alveolar crest with maximum simplicity, it compacts the bone and prepares the implantation tunnel, eliminating the use of rotating drills and all other systems currently in use.
P.E.C. technique advantages
- It uses bone viscoelasticity properties;
- It obtains permanent and passive bone crest plastic deformation, devoid of strains;
- Its particular design allows rapid progression with full bone preservation;
- The use of P.E.C. inserts biostimulates tissues;
- It intensifies natural regenerative properties.
SB P3001
Ø 1,2 – 2 mm
PWR ULT 30
VIBRA 100
SB P3002
ø 1,7 – 2,6 mm
PWR ULT 30
VIBRA 100
SB P3003
ø 2,2 – 3 mm
PWR ULT 30
VIBRA 100
SB P3004
ø 2,5 – 3,3 mm
PWR ULT 30
VIBRA 100
SB P3005
ø 3 – 3,8 mm
PWR ULT 30
VIBRA 100
SB P3006
ø 3,5 – 4,3 mm
PWR ULT 30
VIBRA 100
N.B: If you exceed the recommended settings, we disclaim responsibility and guarantee.
Kit P.E.C. technique steps
Step 1
- Open the flap and display the ridge.
- Middle crest incision using SB P0700 tip and Surgybone device.
Step 2 – 3 – 4 – 5 – 6 – 7 – 8
- The first tip to use is 3001, cutting on the top.
- Make the first expansion with quick and vertical movements.
- The action has to be light reducing the pressure and lifting the tip repeatedly.
- This action has to be repeated between a misuring notch and the other.
- It is advisable to combine a rotary action right and left (for about 30° angular) in order to obtain a clean implant site.
- Use tips in progression starting from the thinnest to the thickest and end with the wanted tip.
